MINI-Z AWD MHS／ASF2.4GHz System MA-030EVO Chassis Set

MINI-Z AWD MHS／ASF2.4GHz System MA-030EVO Chassis Set — an officially-licensed scale body riding on Kyosho's legendary MR-03 Mini-Z RWD chassis. Factory-finished, factory-painted, and Readyset-RTR: drop in batteries, pair the included 2.4 GHz Syncro KT-531P transmitter, and you're driving in minutes.

New AWD chassis set with separate receiver unit to use with your choice of transmitter joins the EVO series lineup! Show more The separable receiver design pioneered on the MR-03EVO is now available with the new AWD model MA-030EVO, based on the FWD MA-03F chassis. The MINI-Z was originally designed with an integrated receiver, servo and speed controller, however on the MR-030EVO the receiver was designed to be purchased and installed as a separate unit to allow the model to be used with other makes of transmitter such as KYOSHO (KT18/EX-6/EX-6R/KT-531P/KT-432PT), KO (EX-2/EX-RR), Futaba (T7PX/T7XC/T4PM), Flysky (Noble NB4). In addition, the highest AWD series spec MA-020VE PRO included a 3-stage steering servo unit, but the new MA-030EVO includes the even higher spec 5-stage gear type from the MR-03.

Why the MR-03 RWD Platform?

• True rear-wheel-drive feel — momentum-based driving that rewards smooth throttle inputs, just like the real thing
• Wide tuning window — swappable motor mounts (LM/MM/HM), pinions 6T-9T included, adjustable front tread & suspension spacers
• Compact 1/27 scale — drives in a parking spot or your living-room loop, but is fully compatible with the global Mini-Z racing scene
• 2.4 GHz Syncro KT-531P radio with sport-grade trims and dual-rate steering

Specifications

• *Scale: 1/27.6 *Length: 126.0mm *Width: 65.0 - 76.0mm (adjustable by wheel offset) *Height: 36.0mm *Chassis Type: MA-030 *Wheelbase: 94.0mm (only with strut rear suspension installed), 98.0mm (factory assembled) *Weight: 135g *Brushless 8500KV *Gear Ratio: 7.2, 6.4, 6.0, 5.7, 5.3, 5.0, 4.5:1 *Tire Diameter (F/R): sold separately *Tire Width (F): sold separately *Tire Width (R): sold separately *Transmitter: Not included *Top speed: approx. 17km/h *Runtime: approx. 50min.

What's in the Box

• CHASSIS SET CONTENTS *Factory-assembled chassis equipped with EVO main unit installed *Pinion Gears (15T, 17T, 19T, 21T) *DWS conversion parts *Front tread conversion parts *Pinion gear removal tool *Spare wheel nuts *Wheel wrench *Center shaft for L wheelbase *Wide rear suspension arms for DWS *swing shafts (4 x long) *Spur gears (27T, 29T, 31T)

Required to Run

• REQUIRED FOR OPERATION *8 x AAA batteries *Auto Scale Collection (body, wheels and tires) *Transmitter *MINI-Z EVO receiver unit compatible with the transmitter used

About Kyosho Mini-Z

The Mini-Z line has been the gold standard for serious 1/27-scale R/C since 1999. Kyosho's RWD series — first launched in 2013 and continuously refined — pairs the legendary MR-03 chassis with new licensed body shells from across motorsport history. As an authorized dealer, Podium Hobbies ships every Mini-Z factory-sealed with full Kyosho warranty support.

Genuine Kyosho part #32180. Photos & specifications courtesy of Kyosho America.
